EVENTURI Carbon Air Intake for Toyota Yaris GR

New product

Performance Increase : 18ft-lb

More details

1 569,00 €

tax incl.

Payez en 3x ou 4x sans frais

Payez en plusieurs fois

  • Cofidis 3 fois sans frais à partir de 523,00 €
  • Cofidis 4 fois sans frais à partir de 392,25 €

EVENTURI Carbon Air Intake for Toyota Yaris GR



The GR Yaris intake was developed through extensive recording of temperature, flow and dynamometer test data. As this is a turbocharged engine, heat and volume were the main considerations during development. This intake system was developed to provide the highest possible flow while maintaining the lowest possible intake temperatures. Each component has been designed to provide a smooth path for the turbo. By ensuring a sealed system, Eventuri has improved the OEM airbox IATs while increasing the internal volume to reduce the pressure drop and therefore reduce turbo pumping losses. By doing so, the turbo is able to operate more efficiently and therefore reaches peak power sooner to produce a net performance gain.

The filter itself has an outer diameter of 210mm or 8.3″ with a filtration area of over 130,000mm^2. The patented Venturi housing has been designed to provide the maximum possible internal volume for the GR Yaris and provides laminar flow to the turbo.

The GR Yaris Eventuri system uses the patented carbon fibre housing which provides an aerodynamically efficient airflow path from filter to turbo. Not just another conical filter with a heat shield, but a unique design that invokes the Venturi effect and maintains laminar flow conditions to reduce drag on the turbo.



Features:

- Performance Increase : 15hp, 18ft-lb



The kit includes:

- Carbon Fiber Patented Venturi Filter Housing with integrated MAF section
- Bespoke High Flow Dry Cone Filter
- Carbon Fiber Inlet Duct
- Rear Tube Manufactured To OEM Specifications
- Custom Made Hardware
- Laser Cut Stainless Steel Brackets
- Custom EPDM Hose
- CNC Machined MAF Boss and Bracket Mounts



Equipment available to order +/- 2/3 weeks



Compatibility:

Model: Toyota Yaris GR 2021



*Images show the optional Eventuri carbon engine cover.

Material Carbon
Power + 15 HP
